GT-55-500

Stretch Film Slitter Rewinder Machine

The GUOTAI brand stands as a beacon of excellence and innovation in the packaging industry, with its high-speed wrapping film machine epitomizing the pinnacle of technological advancement in extrusion blow molding. This machine is meticulously engineered to cater to the...

SUBMIT INQUIRY

Product Description
Main Technical Parameters
Product Highlights

Product Description

The Stretch Film Slitter Rewinder Machine is used to produce winding film, also known as packaging film or stretching film. Mainly used for producing various specifications and thicknesses of winding films to meet the packaging needs of different industries.

upload/1c/202503/machine-stretch-film-01.jpg

upload/1c/202503/machine-stretch-film-02.jpg

Main Technical
Parameters

500mm stretching film machine
MODEL	GT-55-500	GT-55/55-500
Screw diameter	55mm	55x 2mm
L/D ratio of screw	30:1	30:1
Width of T-Die	650mm	650mm
Width of film	500mm	500mm
Thichness of film	0.01-0.05mm	0.01-0.05mm
Structure of film layers	A	A/B
Max output	25-40kg/h	35-55kg/h
Linear speed of machinery	50-100m/min	50-100m/min
Total power	40kw	65kw
Dimension(LxWxH)	7x4x3m	7x4x3m
Weight(about)	3T	4T

Product Highlights

Enhanced tensile strength, puncture resistance, and impact durability: GUOTAI machine manufactured stretch packaging can withstand the strict requirements of transportation and handling. This strength ensures that the film can firmly secure and protect the goods under various conditions without tearing or puncturing, providing peace of mind during transportation and storage.

High clarity and extensibility: making the packaged goods visually attractive while facilitating identification and inspection
